Belt type | Fabric type | Single Fabric strength (N/mm) | Rubber cover thickness (mm) | Total thickness (mm) | Ply | Belt width (mm) | Belt length (m)/roll | |
Top rubber | Bottom rubber | |||||||
Cotton Canvas (CC) conveyor belt | CC-56 | 56 | 3.0-6.0 | 1.5-6.0 | 3-30 | 3-12 | 300-2800 | 200 |
Nylon (NN) conveyor belt | NN100 | 100 | ||||||
NN150 | 150 | |||||||
NN200 | 200 | |||||||
NN250 | 250 | |||||||
NN300 | 300 | |||||||
NN400 | 400 | |||||||
NN500 | 500 | |||||||
NN600 | 600 | |||||||
Polyester (EP) conveyor belt | EP100 | 100 | ||||||
EP150 | 150 | |||||||
EP200 | 200 | |||||||
EP250 | 250 | |||||||
EP300 | 300 | |||||||
EP350 | 350 | |||||||
EP400 | 400 | |||||||
EP500 | 500 | |||||||
EP600 | 600 | |||||||
Rubber performance levels of conveyor belt
Level Code | Tensile strength Mpa≥ | Elongation at break % ≥ | Wear mm3 ≤ |
D | 18 | 400 | 90 |
H | 25 | 450 | 120 |
L | 20 | 400 | 150 |
P | 14 | 350 | 200 |
Note:D-strong wear working conditions;H-strong draw crack working condition;L-general working conditions;P-oil resistant,heat resistant,acid and alkali resistant,cold resistant and general flame resistant conveyor belt. | |||
